Product Description
Product Name | Electric Pallet Truck | |
Power type | Electric | |
Operation type | Pedestrain | |
Rated load | KG | 1500 |
Load center distance | MM | 600 |
Load distance centre of drive axle to fork | MM | 950 |
Wheelbase | MM | 1180 |
Service weight | KG | 120 |
Axle loading, laden front/rear | KG | 480/1140 |
Axle loading, unladen front/rear | KG | 90/30 |
Tyre type | Polyurethane | |
Lowered height | MM | 82 |
Overall length | MM | 1550 |
Length to face of forks | MM | 400 |
Overall width | MM | 695/590 |
Fork dimensions | MM | 55/150/1150 |
Turning radius | MM | 1360 |
Service brake | Electromagnetic | |
Type of drive control | DC | |
Steering design | Mechanical |
High-Power Motor: Equipped with a 750W DC brushed drive motor, delivering robust and consistent power output for heavy-duty material handling tasks. The motor’s high torque ensures smooth acceleration and reliable performance even under full-load conditions, making it ideal for frequent starts and stops in warehouses and logistics centers.
External Charger: Standardly fitted with a 24V/10A external charger that enables rapid charging cycles, reducing downtime and improving operational efficiency. A wide range of optional chargers with different specifications (e.g., 24V/15A, 24V/20A) are available to meet diverse working conditions, including high-volume production lines and long-hour operation scenarios.
Quick-Change Battery: Features a fast-swappable 24V/20AH lithium-ion battery pack, designed to meet the demand for extended operating time without interrupting workflow. The battery’s lightweight and compact design allows for easy replacement by a single operator, ensuring minimal disruption to production schedules.
Small Turning Radius: The entire vehicle is engineered with a compact structure, lower chassis, and ultra-small turning radius, enabling flexible and efficient maneuvering in tight spaces such as narrow aisles, crowded storage areas, and confined loading docks. This design significantly reduces the time required to navigate around obstacles, enhancing overall productivity.
Standard Upright Walking Mode: Built-in upright walking capability ensures stable and safe operation in applications that require vertical movement, such as tailgate loading/unloading and working in ultra-narrow spaces. The mode provides precise control and reduces the risk of collisions, making it suitable for high-precision material handling tasks.
Wide Drive Wheels: The use of wide drive wheels increases the ground contact area, improving traction and stability on various surfaces (e.g., concrete floors, warehouse tiles, and slightly uneven ground). This design enhances the riding comfort and reduces the risk of wheel slip, ensuring smooth and consistent movement even at low speeds.
Lightweight Body Structure: The vehicle’s body is constructed with lightweight materials, which not only reduces the overall weight but also lowers the energy consumption of the motor. This design helps to extend the battery life and reduce operational costs, making it an eco-friendly and cost-effective choice for long-term use.
Product Feature
Durable All-Metal Construction
One of the key advantages of our electric pallet truck is its all-metal construction. Unlike other models that may have plastic components, our electric pallet truck is built to last with a sturdy metal body that can withstand the rigors of daily use in a busy warehouse environment. This durability ensures that our electric pallet truck will continue to perform reliably over time, reducing the need for frequent repairs or replacements.
Enhanced Safety Features
Safety is paramount when it comes to operating heavy machinery, and our electric pallet truck is equipped with a range of features to ensure the safety of both the operator and those working in the vicinity. From anti-slip platforms to emergency stop buttons, our electric pallet truck is designed with safety in mind. Additionally, our electric pallet truck is equipped with sensors that can detect obstacles in its path, preventing accidents and injuries in the workplace.
Efficient Performance
In addition to its durability and safety features, our electric pallet truck also offers efficient performance that can help streamline operations in a warehouse or distribution center. With a powerful motor and smooth acceleration, our electric pallet truck can easily maneuver heavy loads with precision and control. This efficiency not only saves time but also reduces the risk of damage to goods during transport.
Easy to Maintain
Our electric pallet truck is designed for ease of maintenance, with accessible components that can be easily serviced or replaced as needed. This ensures that our electric pallet truck can be kept in optimal working condition with minimal downtime, allowing for uninterrupted productivity in the workplace.
In conclusion, our electric pallet truck stands out from the competition with its durable all-metal construction, enhanced safety features, efficient performance, and ease of maintenance. Whether you are looking to improve efficiency in your warehouse operations or enhance safety for your employees, our electric pallet truck is the ideal solution for your material handling needs.
