| Quantity: | |
Model | CPD15TV8 | CPD18TV8 | CPD20TV8 | |
Power type | electric | electric | electric | |
Operation type | Seated | Seated | Seated | |
Rated load | KG | 1500 | 1800 | 2000 |
Load center distance | MM | 500 | 500 | 500 |
Service weight (including battery) | KG | 3089 | 3238 | 3608 |
Tyre type, driving wheels /steering wheels | Solid tire | Solid tire | Solid tire | |
| Maximum lifting height of standard door frame | MM | 3000 | 3000 | 3000 |
| Roof protection (cockpit) height | MM | 2160 | 2160 | 2160 |
| Length of the vertical surface of the fork upon arrival | MM | 1990 | 2100 | 2100 |
| Turning radius | MM | 1570 | 1680 | 1680 |
| Walking speed, full load/empty load | km/ h | 13/14 | 13/14 | 13/14 |
| Battery voltage/nominal capacity | V/ Ah | 80/240 | 80/300 | 80/360 |
1、Meet the operation requirements of cold storage at -40°C;
2、High-protection-grade electrical components;
3、Use low-temperature resistant hydraulic oil and special wiring harnesses;
4、After special process treatment, the anti-rust and anti-corrosion ability is enhanced.
5、High-performance rubber tires specifically designed for cold storage, enhancing grip;
6、The three-point design offers greater mobility.
7、Low-temperature resistant and waterproof treatment
High-protective-grade electrical components are selected to effectively prevent the influence of low temperatures and condensation water.
It adopts low-temperature resistant hydraulic oil, which can meet the operation requirements in a low-temperature environment above -40 degrees Celsius.
Use dedicated wiring harnesses for low-temperature environments to ensure long-term use in low-temperature conditions and extend service life.
8、Rust and corrosion prevention treatment
The hydraulic system has been specially treated to enhance its anti-corrosion grade.
The structural components such as the vehicle body and mast are treated with special processes to enhance their rust and corrosion resistance.
9、Anti-slip measures
High-performance rubber tires specifically designed for cold storage, enhancing grip on warm and slippery ground.
